DIMENSIONS

• • Overall length: 5224 mm
  • Overall width: 1900 mm
  • Overall height: 1097 mm (including FOM roll hoop camera)
  • Wheelbase: 3135 mm
  • Overall weight: 720 kg (driver on-board)

ENGINE

• • V6 - 3.4 litre single turbo charged Mecachrome engine.
  • Rated to 620 HP @ 8750 rpm.
  • Fly by wire accelerator system.
  • Rebuild after 8000 km.
  • Maximum Torque 600 Nm.

PERFORMANCES

• A
  • cceleration: 0 - 100 km/h, 2.90 sec
  • Acceleration: 0 - 200 km/h, 6.60 sec
  • Maximum speed: 335 km/h (Monza aero configuration + DRS)
  • Max. braking deceleration -3.5 G
  • Max. lateral acceleration +/- 3.9 G

SAFETY STANDARDS

• • Full FIA F1 2017 safety standards.
  • Halo F1 specification.

MONOCOQUE AND BODYWORK

• • Survival cell - Sandwich Carbon/aluminium honeycomb structure made by Dallara.
  • Front and rear wing - Carbon structures made by Dallara.
  • Bodywork - Carbon - Kevlar honeycomb structures made by Dallara.

DRS

• • Same functionality of DRS used in Formula One.
  • Hydraulic activation.

GEARBOX

• • 6-speed longitudinal Hewland sequential gearbox.
  • Electro-hydraulic command via paddle shift from steering wheel.
  • ZF SACHS Carbon clutch.
  • No on-board starter, anti-stall system.
  • Non hydraulic ramp differential.

FUEL CELL

• FIA Standard.
• Premier FT5 125 litres.

ELECTRONIC FEATURES

• • Magneti Marelli Marvel SRG 480 ECU/GCU including data logging system.
  • Magneti Marelli PDU 12-42 power supply management unit.
  • CAN data acquisition pre-equipment.
  • Beacon receiver.

SUSPENSION

• • Double steel wishbones, pushrod operated, twin dampers and torsion bars suspension (F) and spring suspension (R).
  • Adjustable ride height, camber and toe.
  • Two way (F) / Four way (R) adjustable Koni dampers.
  • Adjustable anti-roll bar (Front/Rear).

BRAKES

• • 6 pistons monobloc Brembo callipers.
  • TBC carbon-carbon brake discs and pads.

WHEELS AND TYRES

• • F1 2016 standard wheel dimension.
  • O.Z. Racing.
  • Magnesium rims
  • 13" x 12" front F1 2016 standard wheel dimension.
  • 13" x 13.7" rear F1 2016 standard wheel dimension.
  • F2 specific Pirelli slick / wet tyres.

STEERING SYSTEM

• • Non assisted rack and pinion steering system.
  • XAP steering wheel with dashboard, marshalling display, gear change and clutch paddles, marshalling & VSC display.

CAMERA EQUIPMENT

• Roll hoop, nose cone and face shot camera pre-equipment.
